SQ-50 Fiber Laser Coding System

SYSTEM SPECIFICATIONS

• Laser Type – 50W fiber laser source
• Laser Wavelength – 1.064μm (1064nm)
• Laser Galvanometer – High-precision 2-dimensional high-speed scanning method
• Controller and Operating System – 10” touchscreen controller running Linux®
• Cooling Method – Air-cooled
• Power Consumption – <500W
• Marking Area – 110mm x 110mm standard, optional lenses up to maximum 500mm x 500mm
• Reflector Size – 8.5mm
• Production Line Speed – 0 – 300m/min (varies according to substrate and message)
• Marking Speed – Up to 1200mm/s
• Character Size – Adjustable in marking area, no character line limits within marking area
• Marking Line Number – Code Rotation – 0 to 360°
• Drawing Types – Dot matrix and vector
• Positioning Method – Red light positioning and auto focusing for simple setup
• Software Features – Counter, lot counter shift code, time and date, expiration date, 2D and linear bar codes
• Bar Code Symbologies – Code128, Code39, Code93, EAN13, PDF417, 01Code, QR, DataMatrix, GS1-DM, AztecCode, HanxinCode, DotCode
• Image Formats – bmp, dxf, jpg, plt, png
• Operating Languages – English, Chinese, German, Spanish, French, Italian, Japanese, Korean, Portuguese, Hindi, Russian, Turkish, Arabic, Persian
• Safety Features – Integrated key switch and interlock relay included for safety on the production floor; customer provided shielding necessary to prevent eye or skin exposure
• Interfaces – RS-232C, USB2.0, Ethernet, I/O

OPTIONAL ACCESSORIES

• Print Trigger – Optical, fiber optic, ultrasonic, laser, metal proximity, capacitive proximity
• Encoder – For operation with variable speed conveyors
• Mobile Stands – Heavy duty stand with ability to rotate laser controller in any direction and easily raise and lower marking machine by a single operator; includes casters for easy transportation within plant
• 90 Degree Head Pivot Extension – Mirror assembly that allows marking head to point lens in line with unit axis
• Hand Held 10” Touchscreen Controller – Allows complete control of the system when access is limited due to mounting requirements
• Laser Fume Extraction Systems – SQ-LFX or SQ-LFX PVC for the proper extraction of laser application fumes
• Installation and Training – On-site installation and training available
